DEEP DRAW applications require the utmost in precision control and adjustable positioning, and Sutherland’s hydraulic deep draw presses set the standard for quality and reliability. For cases that push materials to their limit, such as producing oil filters or metal kitchen sinks, you need total control at every stage of the stroke. Sutherland’s deep draw hydraulic presses feature our advanced I-PRESS control with programmable motion & pressure profiles, allowing for higher quality parts and more efficient production.

Deep draw hydraulic press applications require the utmost in precision control and adjustable positioning. Sutherland’s deep draw presses set the standard.

SERVICE, WARRANTY & SUPPORT

Learn more >

FEATURES & COMPONENTS

Press Control

I-PRESS HYDRO Press Control with Multi-Point Edit screen
I-PRESS user Friendly Easy Navigation Screens
10” HD Color Touchscreen
I-PRESS Connected Enterprise for Remote Login
Realtime Status Readouts
Hanging Swivel MOS/Master Operation Station
Tonnage Monitor
200 + Job Memory
12 Programmable Cams
16 Die Monitors
130 separate function monitors
Fault Monitors to Protect Press, Automation & Tooling
Step-by-step fault diagnostics
Operator and supervisor access levels
Performance Level D, Category 3 safety functions
Operator/ Maintenance documentation viewable via pdf
User customizable PLC access
Ethernet I/P Connectivity

I-PRESS HYDRO®
Multi-Point Edit Screen

Standard Features

Rotary Encoder with Time & Distance Brake Monitor
Floor Mounted MEP-Main Panel
20% Open Space in MEP for future items
Mobile T-Stand Run Station
Motorized Slide Adjustment with Mechanical Read Out
OMPI Combination Dry Clutch and Brake with Dual Safety Air Valve
Automatic Lubrication System with Electronic Monitor Cycle Switch
Automatic Air Counter Balance Oiler
Hydraulic Overload System (HOLP) integrated with a key switch located on MOS Operator Control

Mobile T-Stand
Run Station

Safety Equipment

Adjustable Safety Die Block Electrically Interlocked to Emergency Stop Circuit
Flywheel Brake for Quick Stopping of Flywheel during die maintenance or die change
Light Curtains for FRONT & REAR 40" (optional)
Light Curtains for FRONT & REAR 30" (optional)

Hydraulic Fluid Management

Servo motor drives high pressure German pump
Main tank with filtration, magnets and cleanout panels
Prefill valves at top of main cylinders
Limited piping, connections and flanges
Gun drilled precision manifolds for fluid distribution
High pressure testingp orts on manifolds
Valve action charts, model, pressure & I/O

Installation & Service

Trucking, rigging & foundation upon request
Technicians for press start up and training
Preventative Maintenance Programs at 6-12 months
3-2-1 Warranty based on multi-shift use
